Features
Double-double pump open-loop hydraulic system
Double-double pump open-loop hydraulic system , the main pump and gear pump series, the pump and valve block all use of the famous brands Rexroth, Kawasaki products.
Powered by China’s first brand Deutz Dalian, Weichai cost-effective products.
Integrated lessons well-known enterprises at home and abroad over the design advantages.
Intelligent integrated control circuit used Mitsubishi,Omron,Schneider,Matsushita
Imported five curve speed diesel engine throttle control computor,effetively reducing labor intensity.
dual-circut,big oil,the oil temperature
Mandatory emissions can be controlled large air-cooled radiator,dual-circut,big oil,the oil temperature controlled.
Parameter
| The pumping distance is vertical/horizontal | m | 60－80（20tier）/300 | |
| engine performance | Maximum concrete throughput | m3/h | 45 |
| Concrete conveying pressure | MPa | 10-13 | |
| Concrete cylinder specification&journey | mm | Φ200×1000 | |
| bucket capacity & filling height | L× Hmm | 400×1400 | |
| Outlet diameter | mm | Φ180 | |
| power system | Diesel rating | kW/r | 68-72/1800-2200 |
| Diesel engine model | WP4.1D80E201 | ||
| hydraulic system | Main oil pump power | K5V140S-101R－D5T-F16 | |
| With hydraulic stepless speed regulation | |||
| Hydraulic system form | K6-0514 intelligent single pump hydraulic system | ||
| type of cooling | Double channel radiator | ||
| Other Parameter | Maximum aggregate particle size allowed | mm | macadam: 10-35 |
| boundary imension： | mm | 5400X1920X2520 | |
| weight | kg | 3500 | |
